World’s Thinnest Bezels for Multi-Monitor Environments
The monitor features 1 mm ultra-slim bezels on the sides and top with black borders of 4.3 mm and a depth of a mere 47.9 mm. This makes for an attractive design that blends in with the desktop and reduces eye movement in a multi-monitor setup.
Say Goodbye to Tired Eyes
Clear View From All Angles
The monitor uses an LED-backlit IPS (in-plane switching) LCD panel with 178° viewing angle that minimizes color shift and contrast changes when viewing the screen at an angle.
Auto Brightness Control
To prevent eye fatigue, a brightness sensor called Auto EcoView detects the changes in the ambient brightness that occurs throughout the day and automatically adjusts the screen to the ideal brightness level.
Adjustable to Less Than 1% of Maximum Brightness
In a dimly-lit work environment, a monitor with low brightness settings is more comfortable to use. With its LED backlight, the monitor is adjustable to 1 cd/m² which is less than 1% of the maximum.
Due to the way brightness is controlled on LED backlights, a small number of people perceive flicker on their screen which causes eye fatigue. The FlexScan EV series utilizes a hybrid solution to regulate brightness and make flicker unperceivable without any drawbacks like compromising color stability.
Less Blue Light Reduces Eye Fatigue
In the visible light spectrum, blue light has wave lengths adjacent to ultraviolet light. Compared to the factory preset setting of 6,500 K of typical LCD monitors, Paper Mode is closer to the spectral distribution with long reddish wavelengths so it reduces the amount of blue light, a cause of eye fatigue, and helps prevent eyestrain when reading documents.
Stefan Hartter, Head of Calibration and Maintenance at TÜV Rheinland Japan, commented, "We have measured EIZO FlexScan EV Series monitors with different brightness levels and display modes (blue-light strength, wavelength, etc.). We confirmed that the FlexScan EV Series is truly flicker-free and provides eye-pleasing images even in low-brightness environments."
Lower Your Costs
LED Backlights – Less Power, Longer Life
Compared to CCFL backlights, LED backlights last longer and consume less power. They are also mercury-free for minimal environmental impact.
Reduce Power by up to 30%
A new feature called EcoView Optimizer 2 saves energy by up to 30% by reducing the backlight brightness and increasing the gain. To maintain image quality, EcoView Optimizer 2 only boosts the gain with a screen consisting mostly of dark content because the accompanying reduction in brightness is almost unperceivable.
EIZO guarantees this product will be free from bright sub-pixels for six months from purchase date for purchases made on September 1, 2015 or later.
Presence Sensor for Energy Savings
A presence sensor called EcoView Sense prompts the monitor to switch to power save mode when you are absent and then power on again when you return. It even works in a multi-monitor setup so all monitors remain on when you're at your desk.
A manufacturer’s 5-year warranty covers all components including the LCD panel to ensure a long service life. This warranty is 2-years or 67% longer than the standard 3-year warranty of most monitor brands for significantly lower running costs.
Simplify Screen Adjustment with EIZO-Developed Software
ScreenManager Pro for Personal Settings
ScreenManager Pro lets users adjust color and EcoView settings with the mouse and keyboard instead of the on-screen display menu. It also offers multimonitor matching which allows adjustments to be applied to all FlexScan monitors connected to a single PC.
EIZO Monitor Configurator for Administrators
EIZO Monitor Configurator lets system administrators control the settings of all FlexScan EV monitors with a USB connection. The settings of one monitor can be saved as an xml file and can apply to other monitors via USB or office network.
|Model Variations||With FlexStand, Without Stand|
|Cabinet Color||Gray, Black|
|Size||23.8" / 60 cm (604 mm diagonal)|
|Native Resolution||1920 x 1080 (16: 9 aspect ratio)|
|Viewable Image Size (H x V)||527 x 296.4 mm|
|Pixel Pitch||0.2745 x 0.2745 mm|
|Display Colors||16.77 million|
|Viewing Angles (H / V, typical)||178°, 178°|
|Brightness (typical)||250 cd/m2|
|Contrast Ratio (typical)||1000:1|
|Response Time (typical)||5 ms (Gray-to-gray)|
|Input Terminals||D-Sub mini 15 pin x 1, DVI-D 24 pin x 1 (with HDCP), HDMI x 1 (with HDCP), DisplayPort x 1 (with HDCP)|
|Digital Scanning Frequency (H / V)||
DVI: 31 - 68 kHz, 59 - 61 Hz
DisplayPort: 31 - 68 kHz, 59 - 61 Hz
HDMI: 15 - 68 kHz, 49 - 61 Hz
|Analog Scanning Frequency (H / V)||31 - 81 kHz, 55 - 76 Hz|
1 port for monitor control
2-port USB hub
|Speakers||1.0 W +1.0 W|
|Input Terminals||3.5 mm stereo jack|
|Output Terminals||3.5 mm headphone jack|
|Sound Adjustment||Volume, Source (DisplayPort, HDMI)|
|Power Requirements||AC 100 - 120 V / 200 - 240 V, 50 / 60 Hz|
|Maximum Power Consumption||47 W|
|Typical Power Consumption||12 W|
|Power Save Mode||Less than 0.3 W|
|Power Management||Power Save (VESA DPM, DisplayPort Rev. 1.1a, and DVI DMPM), Eco Timer|
|Features & Functions|
|Preset Modes||Color mode (Paper, Movie, sRGB, User1, User2, DICOM)|
|OSD Languages||English, French, German, Italian, Japanese, Simplified and Traditional Chinese, Spanish, Swedish|
|Dimensions (Landscape, W x H x D)||537.6 x 368 - 473.5 x 233 mm|
|Dimensions (Without Stand, W x H x D)||537.6 x 317.6 x 47.9 mm|
|Net Weight||6.2 kg / 13.7 lbs|
|Net Weight (Without Stand)||3.8 kg / 8.4 lbs|
|Height Adjustment Range||140 mm|
|Tilt||35° Up, 5° Down|
|Pivot||90°(both clockwise and counter clockwise)|
|Hole Spacing (VESA Standard)||100 x 100 mm|
|Operating Temperature||5 - 35 °C|
|Operating Humidity (R.H., non condensing)||20 - 80 %|
|Certifications & Standards (Please contact EIZO for the latest information.)||TCO Displays 7, EPEAT Gold (US), TUV/Ergonomics, TUV/GS, RCM, CE, CB, cTUVus, FCC-B, Canadian ICES-003-B, TUV/S, VCCI-B, EPA Energy Star, RoHS, WEEE, China RoHS, CCC, EAC|
|Supplied Accessories (May vary by country. Please contact EIZO for details.)||AC power cord, signal cables (DisplayPort - DisplayPort), USB cable, EIZO LCD Utility Disk (PDF user's manual), setup guide|
- 2 With current LCD technology, a panel may contain a limited number of missing or flickering pixels.
- 5 If the monitor is left on continuously over a long period of time, dark smudges or burn-in may appear. To maximize the life of the monitor, we recommend the monitor be turned off periodically.
